Droid Tesla

Droid Tesla – a magnificent simulator of electric circuits for Android devices. You will be able to simulate different devices used in integrated circuits.

DroidTesla Simulator uses Kirchhoff's current law (KCL), forms a matrix in accordance with KCL. Uses algebraic methods, iterative algorithm of Newton-Raphson, numerical integration methods, offers the trapezoidal integration techniques and many other methods for modeling the device.

For Android is a one of a kind SPICE simulator. The program appearance is as close to what can be seen in the shells of type OrCAD on the PC.

DroidTesla imitates:

• Resistor

• Capacitor

• Inductor

• Potentiometer

• Light Bulb

• Ideal operational amplifier

• Bipolar junction transistor (NPN PNP)

• MOSFET N-channel depletion

• MOSFET N-channel enhancement

• MOSFET P-channel depletion

• MOSFET P-channel enhancement

• JFET N and P

• PN Diode

• PN Led diode

• PN Zener diode

• AC current source

• DC current source

• AC voltage source

• DC voltage(battery) source

• CCVS - current controlled voltage source

• CCCS - current controlled current source

• VCVS - voltage controlled voltage source

• VCCS - voltage controlled current source

• Square wave voltage source

• Triangle wave voltage source

• AC ampermeter

• DC ampermeter

• AC voltmeter

• DC voltmeter

• Two channe oscilloscope

• SPST Switch

• SPDT Switch

• Voltage controlled switch

• Current controlled switch

• AND

• NAND

• OR

• NOR

• NOT

• XOR

• XNOR

• JK flip-flop

• 7 Segment Display

• a D flip-flop

• Relay

• IC 555

• Transformer

• Graetz Circuit
